Overview of Agile UI

Agile UI is a PHP component framework for building User Interfaces entirely in PHP. Although the components of Agile UI will typically use HTML, JavaScript, jQuery and CSS, the goal of Agile UI is to abstract them away behind easy-to-use component objects.

As a framework it’s closely coupled with Agile Data (https://atk4-data.readthedocs.io/) which abstracts database interaction operations. The default UI template set uses Fomantic-UI (https://fomantic-ui.com) for presentation.

At a glance, Agile UI consists of the following:


Agile UI is designed and built for the Agile Toolkit (https://atk4.org/) platform, with the goal of providing a user-friendly experience when creating data-heavy API / UI backends.

Agile UI Design Goals

Our goal is to offer a free UI framework which can be used to easily develop the most complex business application UI in just a few hours, without diving deep into HTML/JS specifics.

1. Out of the box experience

Sample scenario:

If during the .COM boom you purchased 1000 good-looking .COM domains and are now selling   them, you will need to track offers from buyers. You could use Excel, but what if your   staff needs to access the data, or you need to implement business operations such as accepting offers?

Agile UI is ideal for such a scenario. By simply describing your data model, relations, and operations you will get a fully working UI and API with minimal setup.

2. Compact and easy to integrate

Simple scenario:

Your domains such as "happy.com" receive a lot of offers, so you want to place

a special form for potential buyers to fill out. To weed out spammers, you want   to perform an address verification for filled-in data.

Agile UI contains a Form component which you can integrate into your existing app. More importantly, it can securely access your offer database.

3. Compatible with RestAPI

Simple scenario:

You need a basic mobile app to check recent offers from your mobile phone.

You can set up an API end-point for authorized access to your offer database, that follows the same business rules and has access to the same operations.

4. Deploy and Scale

Simple scenario:

You want to use serverless architecture where a 3rd party company is looking
after your server, database, and security; you simply provide your app.

Agile UI is designed and optimized for quick deployment into modern serverless architecture providers such as: Heroku, Docker, or even AWS Lambdas.

Agile UI / PHP application has a minimum “start-up” time, has the best CPU usage, and gives you the highest efficiency and best scaling.

5. High-level Solution

Simple scenario:

You are a busy person who needs to get your application ready in one hour and then   forget about it for the next few years. You are not particularly thrilled about   digging through heaps of HTML, CSS, or JS frameworks and need a solution   which will be quick and just works.

Overview Example

Agile UI / Agile Data code for your app can fit into a single file. See below for clarifications:

require_once __DIR__ . '/vendor/autoload.php';

// define your data structure
class Offer extends \Atk4\Data\Model
    public $table = 'offer';

    protected function init(): void

        $this->addField('date', ['type' => 'date']);
        $this->addField('offer', ['type' => 'atk4_money']);
        $this->addField('is_accepted', ['type' => 'boolean']);

// create Application object and initialize Admin Layout
$app = new \Atk4\Ui\App('Offer tracking system');

// connect to database and place a fully-interactive Crud
$db = new \Atk4\Data\Persistence\Sql($dsn);
    ->setModel(new Offer($db));

Through the course of this example, We are performing several core actions:

  • $app is an object representing our Web Application and abstracting all the input, output, error-handling, and other technical implementation details of a standard web application.

    In most applications you would want to extend this class yourself. When integrating Agile UI with MVC framework, you would be using a different App class that properly integrates framework capabilities.

    For a Component the App class provides level of abstraction and utility.

    For full documentation see Purpose of App class.

  • $db this is a database persistence object. It may be a Database which is either SQL or NoSQL but can also be RestAPI, a cache, or a pseudo-persistence.

    We used Persistence\Sql class, which takes advantage of a standard-compliant database server to speed up aggregation, multi-table, and multi-record operations.

    For a Component the Persistence class provides data storage abstraction through the use of a Model class.

    Agile Data has full documentation at https://atk4-data.readthedocs.io/.

  • Offer is a Model - a database-agnostic declaration of your business entity. Model object represents a data-set for specific persistence and conditions.

    In our example, the object is created representing all our offer records that is then passed into the Crud Component.

    For a Component, the Model represents information about the structure and offers a mechanism to retrieve, store, and delete date from $db persistence.

  • Crud is a Component class. Particularly Crud is bundled with Agile UI and implements out-of-the-box interface for displaying data in a table format with operations to add, delete, or edit the record.

    Although it’s not obvious from the code, Crud relies on multiple other components such as Grid, Form, Menu, Paginator, and Button.

To sum up Agile UI in more technical terms:

  • Fully utilizes abstraction of Web technologies through components.

  • Contains concise syntax to define UI layouts in PHP.

  • Has built-in security and safety.

  • Decouples from data storage/retrieval mechanism.

  • Designed to be integrated into full-stack frameworks.

  • Abstains from duplicating field names, types, or validation logic outside of Model class.

Best use of Agile UI

  • Creating admin backend UI for data entry and dashboards in shortest time and with minimum amount of code.

  • Building UI components which you are willing to use across multiple environments (Laravel, WordPress, Drupal, etc)

  • Creating MVP prototype for Web Apps.


The component is a fundamental building block of Agile UI. Each component is fully self-sufficient and creating a class instance is enough to make a component work.

That means that components may rely on each other and even though some may appear very basic to you, they are relied on by some other components for maximum flexibility. The next example adds a “Cancel” button to a form:

$button = \Atk4\Ui\Button::addTo($form, [
    'icon' => new \Atk4\Ui\Icon('pencil'),

Button and Icon are some of the most basic components in Agile UI. You will find Crud / Form / Grid components much more useful:


Using Components

Look above at the Overview Example, component GRID was made part of application layout with a line:


To render a component individually and get the HTML and JavaScript use this format:

$form = new Form();
$form->setModel(new User($db));

$html = $form->renderToHtml();

This would render an individual component and will return HTML:

<div class="ui form">
    <form id="atk_form">
       ... fields
       ... buttons

For other use-cases please look into View::renderToHtml()


Factory is a mechanism which allow you to use shorter syntax for creating objects. The goal of Agile UI is to be simple to read and use; so taking advantage of loose types in PHP language allows us to use an alternative shorter syntax:

\Atk4\Ui\Button::addTo($form, ['Cancel', 'icon' => 'pencil'])

By default, class names specified as the first array elements passed to the add() method are resolved to namespace Atk4\Ui; however the application class can fine-tune the search.

Using a factory is optional. For more information see: https://atk4-core.readthedocs.io/en/develop/factory.html


Components rely on HtmlTemplate class for parsing and rendering their HTML. The default template is written for Fomantic-UI framework, which makes sure that elements will look good and be consistent.



Using App class will utilize a minimum of 2 templates:

  • html.html - boilerplate HTML code (<head>, <script>, <meta> and empty <body>)

  • layout/admin.html - responsive layout containing page elements (menu, footer, etc)

As you add more components, they will appear inside your layout.

You’ll also find that a layout class such as Layout\Admin will initialize some components on its own - sidebar menu, top menu.


If you are extending your Admin Layout, be sure to maintain the same property names to allow other components to make use of them. For example, an authentication controller will automatically populate a user-menu with the name of the user and log-out button.

Advanced techniques

By design we make sure that adding a component into a render tree (See Views) is enough, so App provides a mechanism for components to:

  • Depend on JS, CSS, and other assets

  • Define event handlers and actions

  • Handle callbacks

Non-PHP dependencies

Your component may depend on additional JavaScript libraries, CSS, or other files. At the present time you have to make them available through a CDN and HTTPS. See: App::requireJs

Events and Actions

Agile UI allows you to initiate some JavaScript actions from within PHP. The amount of code involvement is quite narrow and is only intended for binding events inside your component without involving developers who use and implement your component.


Some actions can be done only on the server side. For example, adding a new record into the database.

Agile UI allows for a component to do just that without any extra effort from you (such as setting up API routes). To make this possible, a component must be able to use unique URLs which will trigger the callback.

To see how this is implemented, read about Callbacks

Virtual Pages


Extending the concept of Callbacks, you can also define Virtual Pages. It is a dynamically generated URL which will respond with a partial render of your components.

Virtual Pages are useful for displaying a UI on dynamic dialogs. As with everything else, virtual pages can be contained within the components, so that no extra effort from you is required when a component wishes to use a dynamic modal dialog.

Extending with Add-ons

Agile UI is designed for data-agnostic UI components which you can add inside your application with a single line of code. However, Agile Toolkit goes one step further by offering you a directory of published add-ons and installs them by using a simple wizard.

Using Agile UI

Technologies advance forward to make it simpler and faster to build web apps. In some cases you can use ReactJS + Firebase but in most cases you will need to have a backend.

Agile Data is a very powerful framework for defining data-driven business models and Agile UI offers a very straightforward extension to attach your data to a wide range of standard UI widgets.

With this approach, even the most complex business apps can be implemented in just one day.

You can still implement ReactJS applications by connecting it to the RestAPI endpoint provided by Agile Toolkit.


information on setting up API endpoints is coming soon.

Learning Agile Toolkit

We recommend that you start looking at Agile UI first. Continue reading through the Quickstart section and try building some of the basic apps. You will need to have a basic understanding of “code” and some familiarity with the PHP language.

  • QuickStart - 20-minute read and some code examples you can try.

  • Core Concept - Read if you plan to design and build your own components.

    • Patterns and Principles

    • Views and common component properties/methods

    • Component Design and UI code refactoring

    • Injecting HTML Templates and Full-page Layouts

    • JavaScript Event Bindings and Actions

    • App class and Framework Integration

    • Usage Patterns

  • Components - Reference for UI component classes

    • Button, Label, Header, Message, Menu, Column

    • Table and Table\Column

    • Form and Field

    • Grid and Crud

    • Paginator

  • Advanced Topics

If you are not interested in UI and only need the Rest API, we recommend that you look into documentation for Agile Data (https://atk4-data.readthedocs.io/) and the Rest API extension (https://github.com/atk4/api) which is a work in progress.

Application Tutorials

We have written a few working cloud applications ourselves with Agile Toolkit and are offering you to view their code. Some of them come with tutorials that teach you how to build an application step-by-step.


If you represent a group of students that wish to learn Agile Toolkit contact us about our education materials. We offer special support for those that want to learn how to develop Web Apps using Agile Toolkit.

Commercial Project Strategy

If you maintain a legacy PHP application, and would like to have a free chat with us about some support and assistance, please do not hesitate to reach out.

Things Agile UI simplifies

Some technologies are “pre-requirements” in other PHP frameworks, but Agile Toolkit lets you develop a perfectly functional web application even if you are NOT familiar with technologies such as:

  • HTML and Asset Management

  • JavaScript, jQuery, NPM

  • CSS styling, LESS

  • Rest API and JSON

We do recommend that you come back and learn those technologies after you have mastered Agile Toolkit.

Database abstraction

Agile Data offers abstraction of database servers and will use appropriate query language to fetch your data. You may need to use SQL/NoSQL language of your database for some more advanced use cases.

Cloud deployment

There are also ways to deploy your application into the cloud without knowledge of infrastructure, Linux and SSH. A good place to start is Heroku (https://www.heroku.com/). We reference Heroku in our tutorials, but Agile Toolkit can work with any cloud hosting that runs PHP apps.

Hosted Demo showing many functions

There’s a demo available of atk4/ui which shows many of the modules and functions available in atk4. You can watch & use the source code of each example to find best practice examples and to see how to use atk4 in certain application cases.

You can find the demo here: https://ui.atk4.org/demos/

Local Demo/Sandpit

When you download and install atk4 you will find a subdirectory called “demos” in the atk4 repository which also could be locally executed.

Setup the demo

To run the demo:

  • Create a directory called “atk4” and create a separate folder for each repo (ui, data, etc.), in this case “ui”

  • Fork the original repo into this directory

  • Copy the file “db.default.php” from the “atk4/ui/demos” subdirectory

  • Rename the copied file to “db.php”

  • Open the renamed file and edit your database details accordingly to fit to your database

  • Setup an Sqlite file database using a provided script (see below)

  • Open the demos from your browser (e.g. https://localhost/…/demos/)

Setup database with example data

The demo also includes a script that let’s you setup a Sqlite file database with an example data. You will find this script in the subdirectory “atk4/ui/demos/_demo-data/”. To run this script, use the following command:

php atk4/ui/demos/_demo-data/create-db.php
